| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Packaging | Series | ProductStatus | CoreType | Material | Diameter | InductanceFactor(Al) | Tolerance | Gap | EffectivePermeability(µe) | InitialPermeability(µi) | CoreFactor(ΣI/A)mm-1 | EffectiveLength(le)mm | EffectiveArea(Ae)mm² | MinimumCoreCrossSection(Amin)mm² | EffectiveMagneticVolume(Ve)mm³ | Finish | Height | Length |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
T60006L2009W914NANOCRYSTALLINE CORE, 9.8X6.5X4. |
3,606 | 0.99 |
FFQ |
Datasheet |
Box | - | Active | Toroid | - | - | 0.441 (11.20mm) | 25.5 µH | - | Ungapped | - | - | - | 25.6 | 5.94 | - | - | Uncoated | 0.228 (5.80mm) |
|
T60004L2016W620NANOCRYSTALLINE CORE, 16X12.5X6 |
3,231 | 0.00 |
FFQ |
Datasheet |
Box | - | Active | Toroid | - | - | 0.701 (17.90mm) | 15 µH | - | Ungapped | - | - | - | 44.8 | 8 | - | - | Epoxy | 0.315 (8.00mm) |
|
|
T60006L2017W515NANOCRYSTALLINE CORE, 17.5X12.6X |
2,770 | 1.98 |
FFQ |
Datasheet |
Box | - | Active | Toroid | - | - | 0.756 (19.20mm) | 30 µH | - | Ungapped | - | - | - | 47.3 | 11.8 | - | - | Uncoated | 0.319 (8.10mm) |
|
|
T60006L2016W403NANOCRYSTALLINE CORE, 16X10X6, 4 |
2,688 | 2.31 |
FFQ |
Datasheet |
Box | - | Active | Toroid | - | - | 0.705 (17.90mm) | 43 µH | - | Ungapped | - | - | - | 40.8 | 14.4 | - | - | Uncoated | 0.319 (8.10mm) |
|
|
T60006L2025W523NANOCRYSTALLINE CORE, 25X20X10 |
3,254 | 0.00 |
FFQ |
Datasheet |
Box | - | Active | Toroid | - | - | 1.087 (27.60mm) | 28.4 µH | - | Ungapped | - | - | - | 70.7 | 20 | - | - | Uncoated | 0.504 (12.80mm) |
|
|
T60006L2025W380NANOCRYSTALLINE CORE, 25X16X10 |
2,577 | 0.00 |
FFQ |
Datasheet |
Box | - | Active | Toroid | - | - | 1.098 (27.90mm) | 67 µH | - | Ungapped | - | - | - | 64.4 | 36 | - | - | Uncoated | 0.492 (12.50mm) |
|
|
T60006L2030W423NANOCRYSTALLINE CORE, 30X20X10 |
3,125 | 0.00 |
FFQ |
Datasheet |
Box | - | Active | Toroid | - | - | 1.299 (33.00mm) | 66 µH | ±30% | Ungapped | - | - | - | 78.5 | 40 | - | - | Uncoated | 0.492 (12.50mm) |
|
|
T60006L2030W514NANOCRYSTALLINE CORE, 30X20X15 |
3,891 | 0.00 |
FFQ |
Datasheet |
Box | - | Active | Toroid | - | - | 1.291 (32.80mm) | 88 µH | - | Ungapped | - | - | - | 78.5 | 57 | - | - | Uncoated | 0.701 (17.80mm) |
|
|
T60006L2040W424NANOCRYSTALLINE CORE, 40X25X15 |
2,082 | 0.00 |
FFQ |
Datasheet |
Box | - | Active | Toroid | - | - | 1.697 (43.10mm) | 109 µH | - | Ungapped | - | - | - | 102 | 85.5 | - | - | Uncoated | 0.728 (18.50mm) |
|
|
T60006L2012W902NANOCRYSTALLINE CORE, 12X8X4.5 |
2,738 | 0.00 |
FFQ |
Datasheet |
Box | - | Active | Toroid | - | - | 0.555 (14.10mm) | 28 µH | - | Ungapped | - | - | - | 31.4 | 7.2 | - | - | Uncoated | 0.248 (6.30mm) |
|
|
T60006L2012W498NANOCRYSTALLINE CORE, 12.5X10X5 |
3,443 | 0.00 |
FFQ |
Datasheet |
Box | - | Active | Toroid | - | - | 0.563 (14.30mm) | 10 µH | - | Ungapped | - | - | - | 35.3 | 50 | - | - | Uncoated | 0.276 (7.00mm) |
|
|
T60006L2015W865NANOCRYSTALLINE CORE, 15X10X4.5 |
3,000 | 0.00 |
FFQ |
Datasheet |
Box | - | Active | Toroid | - | - | 0.673 (17.10mm) | 27 µH | - | Ungapped | - | - | - | 39.3 | 9 | - | - | Uncoated | 0.256 (6.50mm) |
|
|
T60006L2019W838NANOCRYSTALLINE CORE, 19X15X10 |
2,670 | 0.00 |
FFQ |
Datasheet |
Box | - | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
T60006L2020W450NANOCRYSTALLINE CORE, 20X12.5X8 |
858 | 858.00 |
FFQ |
Datasheet |
Box | - | Active | Toroid | - | - | 0.890 (22.60mm) | 14 µH | - | Ungapped | - | - | - | 51.1 | 24 | - | - | Uncoated | 0.402 (10.20mm) |
|
|
T60006L2020W409NANOCRYSTALLINE CORE, 20X12.5X8 |
2,349 | 0.00 |
FFQ |
Datasheet |
Box | - | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
T60004L2025W622NANOCRYSTALLINE CORE, 25X20X10 |
3,738 | 0.00 |
FFQ |
Datasheet |
Box | - | Active | Toroid | - | - | 1.075 (27.30mm) | 22.5 µH | - | Ungapped | - | - | - | 71 | 19 | - | - | Epoxy | 0.484 (12.30mm) |
|
|
T60006L2025W451NANOCRYSTALLINE CORE, 25X16X10 |
777 | 777.00 |
FFQ |
Datasheet |
Box | - | Active | Toroid | - | - | 1.098 (27.90mm) | 17.55 µH | - | Ungapped | - | - | - | 64.4 | 36 | - | - | Uncoated | 0.492 (12.50mm) |
|
|
T60006L2030W358NANOCRYSTALLINE CORE, 30X20X10 |
3,640 | 0.00 |
FFQ |
Datasheet |
Box | - | Active | Toroid | - | - | 1.299 (33.00mm) | 15.5 µH | - | Ungapped | - | - | - | 78.5 | 40 | - | - | Uncoated | 0.492 (12.50mm) |
|
|
T60004L2030W676NANOCRYSTALLINE CORE, 30X25X15 |
472 | 472.00 |
FFQ |
Datasheet |
Box | - | Active | Toroid | - | - | 1.272 (32.30mm) | 26.5 µH | - | Ungapped | - | - | - | 86.4 | 27 | - | - | Epoxy | 0.689 (17.50mm) |
|
|
T60006L2040W453NANOCRYSTALLINE CORE, 40X25X15 |
2,021 | 0.00 |
FFQ |
Datasheet |
Box | - | Active | Toroid | - | - | 1.697 (43.10mm) | 25 µH | - | Ungapped | - | - | - | 102 | 85.5 | - | - | Uncoated | 0.728 (18.50mm) |
